NominalΦ | Inside | BiardΦ | OutsideΦ | Working pressure | Test pressure | Burst pressure | Bend radius | Weight | ||
|---|---|---|---|---|---|---|---|---|---|---|
| lcnch | dash | mm | mm | mm | bar | psi | bar | bar | mm | kg/m |
| 1/4 5/16 | -04 -05 | 6.4 7.9 | 11.2 12.7 | 13.4 15.0 | 192 175 | 2785 2540 | 384 350 | 770 700 | 100 115 | 0.20 0.23 |
| 3/8 1/2 | -06 -08 | 9.5 7.9 | 15.1 18.3 | 17.4 20.6 | 157 140 | 2280 2030 | 314 280 | 628 560 | 125 180 | 0.31 0.38 |
| 5/8 3/4 | -10 -12 | 15.9 19.0 | 21.4 25.4 | 23.7 27.7 | 105 87 | 1525 1260 | 210 174 | 420 348 | 205 240 | 0.42 0.57 |
| 1 1-1/4 | -16 -20 | 25.4 31.8 | 33.3 40.5 | 35.6 43.5 | 70 43 | 1015 625 | 140 86 | 280 172 | 300 420 | 0.87 1.71 |
| 1-1/2 2 | -24 -32 | 38.1 50.8 | 46.8 60.2 | 50.6 64.0 | 35 26 | 510 375 | 70 52 | 140 104 | 500 630 | 1.38 1.85 |
